American National Carbide 2958-189 American Standard Carbide Turning Insert, DNMG-332-GM, AN2020, Multi-Layered Gold Coated
Item #BC859677

Min Order Qty: 10
American Standard Carbide Turning Insert, DNMG-332-GM ANSI Number, P15-P30, M15-M30 ISO Number, Style: DNMG, 55 Deg Diamond Insert Shape, 3/8"" Inscribed Circle, 332 Insert Seat Size, 3/16"" Insert Thickness, GM Chip-Breaker, 1/32"" Nose Radius, Coating: Multi-Layered Gold, AN2020 Grade, 0 Deg Relief Angle, 0.150"" Mounting Hole, Workpiece Material: Carbon and Alloy Steels
  • Provides excellent thermal wear and mechanical shock resistance
  • Molded-to-size reliability or precision ground
Min Order Qty: 10
BrandAmerican National Carbide
ItemAmerican Standard Carbide Turning Insert
ANSI NumberDNMG-332-GM
ISO NumberP15-P30, M15-M30
StyleDNMG
Insert Shape55 Deg Diamond
Inscribed Circle3/8""
Insert Seat Size332
Insert Thickness3/16""
Chip-BreakerGM
Nose Radius1/32""
CoatingMulti-Layered Gold
GradeAN2020
Relief Angle0 Deg
Mounting Hole Diameter0.150""
Workpiece MaterialCarbon and Alloy Steels
